Using Nx for React and Typescript Monorepos

21 February, 2022

Since the acquisition of Turborepo by Vercel dropped recently, the talk of monorepos has been at a peak on social media. I decided to explore a Turborepo competitor, Nx, and see if how it worked compared my standard workflow (Yarn or Lerna workspaces). I was incredibly trepidatious going in, and I ended up being impressed with how fast and solid it was.

With just a few CLI commands I was able to scaffold out an entire monorepo, a React app, a publishable component library, Storybook, and E2E testing for everything with Cypress. The sentence was probably longer than the commands I ran (not really but still).

I go over the process I went through, and my thoughts on the benefits and negatives of Nx.

Process

Scaffolded new project using npx command. Selected a React project.

npx create-nx-workspace --preset=react

This created a new project with a React app with standard splash screen, and an accompanying Cypress E2E test for the app.

Sample Nx React app

The React app was stored in apps/react-gamepads and the Cypress tests were stored in apps/react-gamepads-e2e.

I wanted components to use in the app, so I scaffolded a new library using the nx CLI for UI components:

nx g @nrwl/react:lib ui

This created a React component library project configured with Typescript, Jest, ESLint, and Babel.

The library has a single <Ui /> component inside (presumably based on name we passed). It also updated the root tsconfig.json with a path alias to the lib, so I could import the components anywhere across the monorepo using the project name as a workspace and library name as the package (e.g. `import { Button } from '@react-gamepads/ui';`).

Next I made a component inside that UI library with:

nx g @nrwl/react:component button --project=ui --export

This created a Button component in libs/ui/src/lib/button/button.tsx. As well as a Jest test. And it exported the button from the library’s index.ts.

I was able to import the Button into the app and see it (without pre-building library or anything — just yarn serve).

Building

Ran yarn build. Only the React app built — not the library...

Deleted the UI library, re-generated it with the --publishable flag and --importPath="@react-gamepads/ui" (basically the name of NPM module - in this case scoped to the “org” or monorepo project).

nx g @nrwl/react:lib ui --publishable --importPath="@react-gamepads/ui"

Re-ran yarn build and saw the library generated in the /dist folder! 🎉

Setting up Storybook

This was incredibly simple thanks to all the install scripts/macros they have in place that automatically update configuration files, generate test files, and even create a Cypress E2E testing environment.

Install the primary Storybook dependency:

yarn add -D @nrwl/storybook

Then add a Storybook configuration to any React library, in this case, our ui:

nx g @nrwl/react:storybook-configuration --name=ui

This will also generate a Storybook .story test for any components you currently have in your library. When you create more components, you can run this command to generate corresponding tests:

nx g @nrwl/react:stories --project=ui

Now you can run or build Storybook:

# Notice we preface with `ui` - name of our lib
nx run ui:storybook
nx run ui:build-storybook

It’s a pretty nifty setup overall, they have Cypress access Storybook for testing, so your E2E tests literally run off the embedded preview from Storybook.

Why Nx

  • Easy to quickly scaffold new monorepos
  • Easy to setup complex projects with many internal and external dependencies
  • Faster to create boilerplate code like libraries, workspaces, or even components and tests.
  • Comes with a suite of tools powered off the platform (like a dependency graph)
  • Can use Yarn or Lerna workspaces format and opt-in to Nx config as needed (for better performance)

Why not Nx

  • A lot of platform specific configuration. Monorepos are handled in special config files.
  • Confusing up-front to developers new to the monorepo style. For example, in some cases the package.json doesn’t contain scripts — and they’re in a project.json file.
  • More to learn. Setup is simplified, but things can be difficult to maintain or extend because it’s all contained in custom platform configurations and APIs. You’re still adding a Webpack build to a “package” or app, but it’s now piped through the project.json build pipeline.
    • This is similar to Turborepo, so it’s hard to hate. Although Turborepo seems to take methods from package.json and run them — all of the configuration in Nx is custom stuff that can be confusing even to devs experienced with monorepos (although probably familiar to those devops engineers making YML pipelines).
  • Different style of monorepo? All dependencies seem to be stored in root package.json - not individual package.json. This means you couldn’t have multiple versions of things like React in the same monorepo. It kinda makes sense if everything is talking to each other, but if I have one module that supports a legacy version of React (or any of it’s dependencies), I’d have to pull it out into a separate project.

Example of negatives

To stress test Nx monorepos I decided to try creating a design system. I opted to use @vanilla-extract/css, which immediately proved to be an issue.

When creating new libraries in Nx, they’re Typescript based and compile using the tsconfig.json. @vanilla-extract/css uses actual build pipelines (like Webpack, esbuild, or Vite).

I could use Nx generators to create a React app with Webpack bundling, but only libraries are “publishable” out of the box.

If I wanted to add esbuild to my project, I’d suddenly have to a lot of Nx-specific things. To run the build process, I needs to create a custom executor. This involves defining a schema, and a task runner in NodeJS. In a normal Lerna or Yarn style monorepo, I’d just add the build script to a package.json...done. It’d take 2 seconds, versus the time it takes to research the Nx API and match their spec.

I was able to find a plugin to generate projects with esbuild setup — but it only worked for Node apps (not React component libraries).

After about an hour of research and digging, I was ready to hop off the Nx train and spin up a simple Yarn workspace.

Takeways

  • Unique monorepo setup where dependencies seem to be kept in root level package.json. Each “package” in the monorepo has a project.json file that defines it - but mostly things like lint or test. Builds seem to be done through tsconfig.json files.
  • Generators are really handy. You can quickly generate “libraries” (like utility modules, or UI components), or apps (React, Angular, even Next or Gatsby). It can also generate things like React components, and scaffold out the Jest and E2E tests.
  • Also has Storybook integration. Can generate stories for React components.
  • Libraries are linked using Typescript path aliasing (see root tsconfig.base.json). When you create a new library, it’ll be under the monorepo name + library name (e.g. @react-gamepads/ui)
  • Still need to manually setup npm and Github publishing
    • Can add -publishable flag when creating a library
  • Can generate
    • React
      • Library
      • Component
      • Web app
      • NextJS / Gatsby
      • Hook
      • Redux Slice
      • Storybook story
      • Cypress test
    • Web apps in general
    • New workspace
    • New npm package
  • Removing generated things isn’t simple?
    • Had to manually go in and find where things were added
    • Would be smarter to only generate on separate branches/commits

Nx or Turborepo or Lerna?

After trying out each option, I’d say that each are almost different products, and offer overlapping features in some cases.

  • Need better monorepo support and you’re ok with learning a little API and overhead? Go for Turborepo or Lerna.
  • Need to improve performance of a waterfall of build scripts? Go for Turborepo or Nx.
  • Want a lot of boilerplate support? Go Nx or Yeoman.

What do you think?

I’m curious to hear if I missed the mark on anything, or if you disagree with any of my negatives. You can reach out on Twitter and let me know your thoughts.
